Octoputer 2U Dense 8 GPU Server

Dense 2U 8-GPU Server with up to 8 Tesla V100 GPUs

Octoputer 2U allows GPU-accelerated applications to scale up in the most compact rack footprint available. This system matches to massively parallel codes and can allow for a an unprecedented rack density of up to 160 GPUs per 42U rack!

Each Octoputer arrives fully integrated with the NVIDIA CUDA Toolkit. It passes rigorous stress tests for over 48 hours prior to shipment.

Need more compute power? Link multiple 2U servers together for an extraordinarily dense cluster.

NVIDIA Tesla Logo

  • Up to 8 NVIDIA Tesla V100 GPUs
  • NVIDIA CUDA Toolkit installed and configured – Ready to run CUDA jobs!
  • Additional slots for EDR InfiniBand 10G/25G/50G/100G Ethernet or storage controllers
  • Up to 56 processor cores
  • Up to 1.50 TB memory
  • Up to 16 TB storage built-in
  • (2) Intel Xeon Xeon Scalable Processor“Cascade Lake-SP” CPUs (clock speed: up to 3.8 GHz)
  • Six-Channel DDR4 2933 Mhz ECC/Registered Memory (12 slots)
  • Up to (8) Hot-Swap 2.5” 12Gbps drive bays
  • Eight PCI-Express 3.0 x16 double-width slots
  • Four PLX 8747 PCI-Express 3.0 Switches (switched architecture)
  • Two half-length, half-height PCI-Express 3.0 x16 slots
  • Removable Storage: rear USB 3.0 ports
  • Two integrated Intel X540 10 Gigabit Ethernet ports
  • IPMI 2.0 with Dedicated LAN Support
  • 4400W 1+1 Redundant High-EfficiencyPower
  • ConnectX-5 100Gb InfiniBand or 10G/25/40/50/100G Ethernet
  • NVIDIA Quadro GPUs for visualization
  • TPM 2.0, with optional TXT support
  • PGI Accelerator Compilers (with OpenACC support) for GPUs
  • Intel compilers, libraries and tools

Supported for Life

Our technicians and sales staff consistently ensure that your entire experience with Microway is handled promptly, creatively, and professionally.

Telephone support is available for the lifetime of your server(s) by Microway’s experienced technicians. After the initial warranty period, hardware warranties are offered on an annual basis. Out-of-warranty repairs are available on a time & materials basis.

System Price: $7,500 to $97,000

Each Microway system is customized to your requirements. Final pricing depends upon configuration and any applicable educational or government discounts.

Call a Microway Sales Engineer for Assistance : 508.746.7341 or
Click Here to Request More Information.

Block diagram of the Octoputer 2U 8-GPU server with Tesla V100
