nvidia-smi: Control Your GPUs

Most users know how to check the status of their CPUs, see how much memory is free or find out how much disk space is free. In contrast, keeping tabs on the health and status of GPUs has historically been more difficult. If you don’t know where to look, it can even be difficult to determine the type and capabilities of the GPUs in a system. Thankfully, NVIDIA’s latest hardware and software tools have made good improvements in this respect.

The tool is NVIDIA’s System Management Interface (nvidia-smi). Depending on the generation of your card, various levels of information can be gathered. Additionally, GPU configuration options (such as ECC memory capability) may be enabled and disabled.

As an aside, if you find that you’re having trouble getting your NVIDIA GPUs to run GPGPU code, nvidia-smi can be handy. For example, on some systems the proper NVIDIA devices in /dev are not created at boot. Running a simple nvidia-smi query as root will initialize all the cards and create the proper devices in /dev. Other times, it’s just useful to make sure all the GPU cards are visible and communicating properly. Here’s the default output from a recent version with one Tesla K80 GPU card:

Tue Apr  7 12:56:41 2015
+------------------------------------------------------+
| NVIDIA-SMI 346.46     Driver Version: 346.46         |
|-------------------------------+----------------------+----------------------+
| GPU  Name        Persistence-M| Bus-Id        Disp.A | Volatile Uncorr. ECC |
| Fan  Temp  Perf  Pwr:Usage/Cap|         Memory-Usage | GPU-Util  Compute M. |
|===============================+======================+======================|
|   0  Tesla K80           On   | 0000:05:00.0     Off |                  Off |
| N/A   32C    P8    26W / 149W |     56MiB / 12287MiB |      0%      Default |
+-------------------------------+----------------------+----------------------+
|   1  Tesla K80           On   | 0000:06:00.0     Off |                  Off |
| N/A   29C    P8    29W / 149W |     56MiB / 12287MiB |      0%      Default |
+-------------------------------+----------------------+----------------------+

+-----------------------------------------------------------------------------+
| Processes:                                                       GPU Memory |
|  GPU       PID  Type  Process name                               Usage      |
|=============================================================================|
|  No running processes found                                                 |
+-----------------------------------------------------------------------------+

Persistence Mode

On Linux, you can set GPUs to persistence mode to keep the NVIDIA driver loaded even when no applications are accessing the cards. This is particularly useful when you have a series of short jobs running. Persistence mode uses more power, but prevents the fairly long delays that occur each time a GPU application is started. It is also necessary if you’ve assigned specific clock speeds or power limits to the GPUs (as those changes are lost when the NVIDIA driver is unloaded). Enable persistence mode on all GPUS by running:
nvidia-smi -pm 1

On Windows, nvidia-smi is not able to set persistence mode. Instead, you need to set your computational GPUs to TCC mode. This should be done through NVIDIA’s graphical GPU device management panel.

GPUs supported by nvidia-smi

NVIDIA’s SMI tool supports essentially any NVIDIA GPU released since the year 2011. These include the Tesla, Quadro, GRID and GeForce devices from Fermi and higher architecture families (Kepler, Maxwell, etc).

Supported products include:
Tesla: S1070, S2050, C1060, C2050/70, M2050/70/90, X2070/90, K10, K20, K20X, K40, K80
Quadro: 4000, 5000, 6000, 7000, M2070-Q, K-series, M-series
GeForce: varying levels of support, with fewer metrics available than on the Tesla and Quadro products

Querying GPU Status

Microway’s GPU Test Drive cluster, which we provide as a benchmarking service to our customers, contains a group of NVIDIA’s latest Tesla GPUs. These are NVIDIA’s high-performance compute GPUs and provide a good deal of health and status information. The examples below are taken from this internal cluster.

To list all available NVIDIA devices, run:

[root@md ~]# nvidia-smi -L
GPU 0: Tesla K40m (UUID: GPU-d0e093a0-c3b3-f458-5a55-6eb69fxxxxxx)
GPU 1: Tesla K40m (UUID: GPU-d105b085-7239-3871-43ef-975ecaxxxxxx)

To list certain details about each GPU, try:

[root@md ~]# nvidia-smi --query-gpu=index,name,uuid,serial --format=csv
0, Tesla K40m, GPU-d0e093a0-c3b3-f458-5a55-6eb69fxxxxxx, 0323913xxxxxx
1, Tesla K40m, GPU-d105b085-7239-3871-43ef-975ecaxxxxxx, 0324214xxxxxx

Monitoring and Managing GPU Boost

The GPU Boost feature which NVIDIA has included with more recent GPUs allows the GPU clocks to vary depending upon load (achieving maximum performance so long as power and thermal headroom are available). However, the amount of available headroom will vary by application (and even by input file!) so users and administrators should keep their eyes on the status of the GPUs.

A listing of available clock speeds can be shown for each GPU (in this case, the Tesla K80):

nvidia-smi -q -d SUPPORTED_CLOCKS

GPU 0000:04:00.0
    Supported Clocks
        Memory                      : 2505 MHz
            Graphics                : 875 MHz
            Graphics                : 862 MHz
            Graphics                : 849 MHz
            Graphics                : 836 MHz
            Graphics                : 823 MHz
            Graphics                : 810 MHz
            Graphics                : 797 MHz
            Graphics                : 784 MHz
            Graphics                : 771 MHz
            Graphics                : 758 MHz
            Graphics                : 745 MHz
            Graphics                : 732 MHz
            Graphics                : 719 MHz
            Graphics                : 705 MHz
            Graphics                : 692 MHz
            Graphics                : 679 MHz
            Graphics                : 666 MHz
            Graphics                : 653 MHz
            Graphics                : 640 MHz
            Graphics                : 627 MHz
            Graphics                : 614 MHz
            Graphics                : 601 MHz
            Graphics                : 588 MHz
            Graphics                : 575 MHz
            Graphics                : 562 MHz
        Memory                      : 324 MHz
            Graphics                : 324 MHz

The above output indicates that only two memory clock speeds are supported (2505 MHz and 324 MHz). With the memory running at 2505 MHz, there are 25 supported GPU clock speeds. With the memory running at 324 MHz, only a single GPU clock speed is supported (which is the idle GPU state). On the Tesla K80, GPU Boost automatically manages these speeds and runs as fast as possible. On other models, such as Tesla K40, the administrator must specifically select the desired GPU clock speed.

To review the current GPU clock speed, default clock speed, and maximum possible clock speed, run:

nvidia-smi -q -d CLOCK

GPU 0000:04:00.0
    Clocks
        Graphics                    : 875 MHz
        SM                          : 875 MHz
        Memory                      : 2505 MHz
    Applications Clocks
        Graphics                    : 875 MHz
        Memory                      : 2505 MHz
    Default Applications Clocks
        Graphics                    : 562 MHz
        Memory                      : 2505 MHz
    Max Clocks
        Graphics                    : 875 MHz
        SM                          : 875 MHz
        Memory                      : 2505 MHz
    SM Clock Samples
        Duration                    : 3730.56 sec
        Number of Samples           : 8
        Max                         : 875 MHz
        Min                         : 324 MHz
        Avg                         : 873 MHz
    Memory Clock Samples
        Duration                    : 3730.56 sec
        Number of Samples           : 8
        Max                         : 2505 MHz
        Min                         : 324 MHz
        Avg                         : 2500 MHz
    Clock Policy
        Auto Boost                  : On
        Auto Boost Default          : On

Ideally, you’d like all clocks to be running at the highest speed all the time. However, this will not be possible for all applications. To review the current state of each GPU and any reasons for clock slowdowns, use the PERFORMANCE flag:

nvidia-smi -q -d PERFORMANCE

GPU 0000:04:00.0
    Performance State               : P0
    Clocks Throttle Reasons
        Idle                        : Not Active
        Applications Clocks Setting : Not Active
        SW Power Cap                : Not Active
        HW Slowdown                 : Not Active
        Unknown                     : Not Active

If any of the GPU clocks is running at a slower speed, one or more of the above Clocks Throttle Reasons will be marked as active. The most concerning condition would be if HW Slowdown or Unknown are active, as these would most likely indicate a power or cooling issue. The remaining conditions typically indicate that the card is idle or has been manually set into a slower mode by a system administrator.

Reviewing System Topology

To properly take advantage of more advanced NVIDIA GPU features (such as GPU Direct), it is often vital that the system topology be properly configured. The topology refers to how the PCI-Express devices (GPUs, InfiniBand HCAs, storage controllers, etc.) connect to each other and to the system’s CPUs. If not correct, it is possible that certain features will slow down or even stop working altogether. To help tackle such questions, recent versions of nvidia-smi include an experimental system topology view:

nvidia-smi topo --matrix

        GPU0    GPU1    GPU2    GPU3    mlx4_0  CPU Affinity
GPU0     X      PIX     PHB     PHB     PHB     0-11
GPU1    PIX      X      PHB     PHB     PHB     0-11
GPU2    PHB     PHB      X      PIX     PHB     0-11
GPU3    PHB     PHB     PIX      X      PHB     0-11
mlx4_0  PHB     PHB     PHB     PHB      X

Legend:

  X   = Self
  SOC = Path traverses a socket-level link (e.g. QPI)
  PHB = Path traverses a PCIe host bridge
  PXB = Path traverses multiple PCIe internal switches
  PIX = Path traverses a PCIe internal switch

Reviewing this section will take some getting used to, but can be very valuable. The above configuration shows two Tesla K80 GPUs and one Mellanox FDR InfiniBand HCA all connected to the first CPU of a server. Because the CPUs are 12-core Xeons, the topology tool recommends that jobs be assigned to the first 12 CPU cores (although this will vary by application). Get in touch with one of our HPC GPU experts if you have questions on this topic.

Printing all GPU Details

To list all available data on a particular GPU, specify the ID of the card with -i. Here’s the output from an older Tesla GPU card:

nvidia-smi -i 0 -q

==============NVSMI LOG==============

Timestamp                       : Mon Dec  5 22:05:49 2011

Driver Version                  : 270.41.19

Attached GPUs                   : 2

GPU 0:2:0
    Product Name                : Tesla M2090
    Display Mode                : Disabled
    Persistence Mode            : Disabled
    Driver Model
        Current                 : N/A
        Pending                 : N/A
    Serial Number               : 032251100xxxx
    GPU UUID                    : GPU-2b1486407f70xxxx-98bdxxxx-660cxxxx-1d6cxxxx-9fbd7e7cd9bf55a7cfb2xxxx
    Inforom Version
        OEM Object              : 1.1
        ECC Object              : 2.0
        Power Management Object : 4.0
    PCI
        Bus                     : 2
        Device                  : 0
        Domain                  : 0
        Device Id               : 109110DE
        Bus Id                  : 0:2:0
    Fan Speed                   : N/A
    Memory Usage
        Total                   : 5375 Mb
        Used                    : 9 Mb
        Free                    : 5365 Mb
    Compute Mode                : Default
    Utilization
        Gpu                     : 0 %
        Memory                  : 0 %
    Ecc Mode
        Current                 : Enabled
        Pending                 : Enabled
    ECC Errors
        Volatile
            Single Bit
                Device Memory   : 0
                Register File   : 0
                L1 Cache        : 0
                L2 Cache        : 0
                Total           : 0
            Double Bit
                Device Memory   : 0
                Register File   : 0
                L1 Cache        : 0
                L2 Cache        : 0
                Total           : 0
        Aggregate
            Single Bit
                Device Memory   : 0
                Register File   : 0
                L1 Cache        : 0
                L2 Cache        : 0
                Total           : 0
            Double Bit
                Device Memory   : 0
                Register File   : 0
                L1 Cache        : 0
                L2 Cache        : 0
                Total           : 0
    Temperature
        Gpu                     : N/A
    Power Readings
        Power State             : P12
        Power Management        : Supported
        Power Draw              : 31.57 W
        Power Limit             : 225 W
    Clocks
        Graphics                : 50 MHz
        SM                      : 100 MHz
        Memory                  : 135 MHz

The above example shows an idle card. Here is an excerpt for a card running GPU-accelerated AMBER:

nvidia-smi -i 0 -q -d MEMORY,UTILIZATION,POWER,CLOCK,COMPUTE

==============NVSMI LOG==============

Timestamp                       : Mon Dec  5 22:32:00 2011

Driver Version                  : 270.41.19

Attached GPUs                   : 2

GPU 0:2:0
    Memory Usage
        Total                   : 5375 Mb
        Used                    : 1904 Mb
        Free                    : 3470 Mb
    Compute Mode                : Default
    Utilization
        Gpu                     : 67 %
        Memory                  : 42 %
    Power Readings
        Power State             : P0
        Power Management        : Supported
        Power Draw              : 109.83 W
        Power Limit             : 225 W
    Clocks
        Graphics                : 650 MHz
        SM                      : 1301 MHz
        Memory                  : 1848 MHz

You’ll notice that unfortunately the earlier M-series passively-cooled Tesla GPUs do not report temperatures to nvidia-smi. More recent Quadro and Tesla GPUs support a greater quantity of metrics data:

==============NVSMI LOG==============

Timestamp                           : Tue Apr  7 13:01:34 2015
Driver Version                      : 346.46

Attached GPUs                       : 2
GPU 0000:05:00.0
    Product Name                    : Tesla K80
    Product Brand                   : Tesla
    Display Mode                    : Disabled
    Display Active                  : Disabled
    Persistence Mode                : Enabled
    Accounting Mode                 : Enabled
    Accounting Mode Buffer Size     : 128
    Driver Model
        Current                     : N/A
        Pending                     : N/A
    Serial Number                   : 0324614xxxxxx
    GPU UUID                        : GPU-81dexxxx-87xx-4axx-79xx-3ddf4dxxxxxx
    Minor Number                    : 0
    VBIOS Version                   : 80.21.1B.00.01
    MultiGPU Board                  : Yes
    Board ID                        : 0x300
    Inforom Version
        Image Version               : 2080.0200.00.04
        OEM Object                  : 1.1
        ECC Object                  : 3.0
        Power Management Object     : N/A
    GPU Operation Mode
        Current                     : N/A
        Pending                     : N/A
    PCI
        Bus                         : 0x05
        Device                      : 0x00
        Domain                      : 0x0000
        Device Id                   : 0x102D10DE
        Bus Id                      : 0000:05:00.0
        Sub System Id               : 0x106C10DE
        GPU Link Info
            PCIe Generation
                Max                 : 3
                Current             : 1
            Link Width
                Max                 : 16x
                Current             : 16x
        Bridge Chip
            Type                    : PLX
            Firmware                : 0xF0472900
        Replays since reset         : 0
        Tx Throughput               : N/A
        Rx Throughput               : N/A
    Fan Speed                       : N/A
    Performance State               : P8
    Clocks Throttle Reasons
        Idle                        : Active
        Applications Clocks Setting : Not Active
        SW Power Cap                : Not Active
        HW Slowdown                 : Not Active
        Unknown                     : Not Active
    FB Memory Usage
        Total                       : 12287 MiB
        Used                        : 56 MiB
        Free                        : 12231 MiB
    BAR1 Memory Usage
        Total                       : 16384 MiB
        Used                        : 2 MiB
        Free                        : 16382 MiB
    Compute Mode                    : Default
    Utilization
        Gpu                         : 0 %
        Memory                      : 0 %
        Encoder                     : 0 %
        Decoder                     : 0 %
    Ecc Mode
        Current                     : Disabled
        Pending                     : Disabled
    ECC Errors
        Volatile
            Single Bit
                Device Memory       : N/A
                Register File       : N/A
                L1 Cache            : N/A
                L2 Cache            : N/A
                Texture Memory      : N/A
                Total               : N/A
            Double Bit
                Device Memory       : N/A
                Register File       : N/A
                L1 Cache            : N/A
                L2 Cache            : N/A
                Texture Memory      : N/A
                Total               : N/A
        Aggregate
            Single Bit
                Device Memory       : N/A
                Register File       : N/A
                L1 Cache            : N/A
                L2 Cache            : N/A
                Texture Memory      : N/A
                Total               : N/A
            Double Bit
                Device Memory       : N/A
                Register File       : N/A
                L1 Cache            : N/A
                L2 Cache            : N/A
                Texture Memory      : N/A
                Total               : N/A
    Retired Pages
        Single Bit ECC              : 0
        Double Bit ECC              : 0
        Pending                     : No
    Temperature
        GPU Current Temp            : 34 C
        GPU Shutdown Temp           : 93 C
        GPU Slowdown Temp           : 88 C
    Power Readings
        Power Management            : Supported
        Power Draw                  : 25.65 W
        Power Limit                 : 149.00 W
        Default Power Limit         : 149.00 W
        Enforced Power Limit        : 149.00 W
        Min Power Limit             : 100.00 W
        Max Power Limit             : 175.00 W
    Clocks
        Graphics                    : 324 MHz
        SM                          : 324 MHz
        Memory                      : 324 MHz
    Applications Clocks
        Graphics                    : 875 MHz
        Memory                      : 2505 MHz
    Default Applications Clocks
        Graphics                    : 562 MHz
        Memory                      : 2505 MHz
    Max Clocks
        Graphics                    : 875 MHz
        SM                          : 875 MHz
        Memory                      : 2505 MHz
    Clock Policy
        Auto Boost                  : On
        Auto Boost Default          : On
    Processes                       : None

Of course, we haven’t covered all the possible uses of the nvidia-smi tool. To read the full list of options, run nvidia-smi -h (it’s fairly lengthy). If you need to change settings on your cards, you’ll want to look at the device modification section:

    -pm,  --persistence-mode=   Set persistence mode: 0/DISABLED, 1/ENABLED
    -e,   --ecc-config=         Toggle ECC support: 0/DISABLED, 1/ENABLED
    -p,   --reset-ecc-errors=   Reset ECC error counts: 0/VOLATILE, 1/AGGREGATE
    -c,   --compute-mode=       Set MODE for compute applications:
                                0/DEFAULT, 1/EXCLUSIVE_THREAD,
                                2/PROHIBITED, 3/EXCLUSIVE_PROCESS
          --gom=                Set GPU Operation Mode:
                                    0/ALL_ON, 1/COMPUTE, 2/LOW_DP
    -r    --gpu-reset           Trigger reset of the GPU.
                                Can be used to reset the GPU HW state in situations
                                that would otherwise require a machine reboot.
                                Typically useful if a double bit ECC error has
                                occurred.
                                Reset operations are not guarenteed to work in
                                all cases and should be used with caution.
                                --id= switch is mandatory for this switch
    -ac   --applications-clocks= Specifies  clocks as a
                                    pair (e.g. 2000,800) that defines GPU's
                                    speed in MHz while running applications on a GPU.
    -rac  --reset-applications-clocks
                                Resets the applications clocks to the default values.
    -acp  --applications-clocks-permission=
                                Toggles permission requirements for -ac and -rac commands:
                                0/UNRESTRICTED, 1/RESTRICTED
    -pl   --power-limit=        Specifies maximum power management limit in watts.
    -am   --accounting-mode=    Enable or disable Accounting Mode: 0/DISABLED, 1/ENABLED
    -caa  --clear-accounted-apps
                                Clears all the accounted PIDs in the buffer.
          --auto-boost-default= Set the default auto boost policy to 0/DISABLED
                                or 1/ENABLED, enforcing the change only after the
                                last boost client has exited.
          --auto-boost-permission=
                                Allow non-admin/root control over auto boost mode:
                                0/UNRESTRICTED, 1/RESTRICTED

With this tool, checking the status and health of NVIDIA GPUs is simple. If you’re looking to monitor the cards over time, then nvidia-smi might be more resource-intensive than you’d like. For that, have a look at NVIDIA’s GPU Management Library (NVML), which offers C, Perl and Python bindings. Commonly-used cluster tools, such as Ganglia, use these bindings to query GPU status.

This post was last updated on 2015-07-07

Eliot Eshelman

About Eliot Eshelman

My interests span from astrophysics to bacteriophages; high-performance computers to small spherical magnets. I've been an avid Linux geek (with a focus on HPC) for more than a decade. I work as Microway's Vice President of Strategic Accounts and HPC Initiatives.
This entry was posted in Administration, Hardware and tagged , . Bookmark the permalink.

Leave a Reply

Your email address will not be published. Required fields are marked *
