Scale Out AMD EPYC Server with High GPU Density
Navion 4U GPU Server delivers a high-density 8/10 NVIDIA H100, L40S, L40, A40, or A30 GPU configuration.
Support the highest GPU density with up to 10 NVIDIA® Datacenter GPUs and 400Gb InfiniBand— either direct attached or with PCI-Express switches.
All hardware and software is preinstalled and tested prior to shipment. These servers can be custom-configured to exact user specifications.
Features
- Up to 10 NVIDIA H100, L40S, L40, A40, or A30 Tensor Core GPUs in switched architecture, up to 8 GPUs direct connect
- Supports GPUDirect® RDMA over PCI-E 5.0 to ConnectX®-7 400Gb NDR InfiniBand adapters
- NVIDIA CUDA® SDK installed and configured-Ready to run CUDA jobs!
- Reliable! Customers commonly use Microway servers for 5+ years.
Specifications
- (2) Processor Socket with AMD EPYC 9004 Series CPUs (clock speed: up to 4.1Ghz)
- Up to 192 processor cores
- Twelve-Channel DDR5 4800 MHz ECC/Registered Memory (24 slots), up to 6 TB total memory
- Eight PCI-Express x16 5.0 double-width slots + one PCI-Express x16 5.0 slots (8 GPU version) OR
- Ten PCI-Express x16 5.0 double-width slots + two PCI-Express x16 5.0 slots (10 GPU version, switched architecture)
- 24 drive bays for hard drives and SSDs, four NVMe ready
- Removable Storage:
- Rear USB 3.0 ports
- Front accessible hot-swap hard drives
- Two integrated 10 Gigabit Ethernet ports
- IPMI 2.0 with Dedicated LAN Support
- 2000W 2+2 high-efficiency power supplies
Accessories/Options
- 10/25/50/100G Ethernet or ConnectX-7 400Gb NDR or ConnectX-6 200Gb HDR InfiniBand
- UPS power backup and surge suppression
Support
Supported for Life
Our technicians and sales staff consistently ensure that your entire experience with Microway is handled promptly, creatively, and professionally.
Telephone support is available for the lifetime of your server(s) by Microway’s experienced technicians. After the initial warranty period, hardware warranties are offered on an annual basis. Out-of-warranty repairs are available on a time & materials basis.
Price
System Price: $9100 to $118,000
Each Microway system is customized to your requirements. Final pricing depends upon configuration and any applicable educational or government discounts.
